AX Electric Single Girder Suspension Overhead Crane
Structural Composition
The main beam is made from Q235-B steel plates and formed by welding. The plates are shot-blasted to Sa2.5 standard before welding, ensuring rust removal and cleanliness. Automatic or semi-automatic (MIG) welding is used. The end carriages are made of rectangular steel tubes or CNC-formed components and equipped with double-flange wheels, buffers, and anti-derailment protection. The main beam and end carriages are connected via high-strength bolts, ensuring structural precision and smooth operation.
Technical Parameters
| Item | Specification |
|---|---|
| Structure Type | Single main beam or H-beam |
| Material | Q235-B steel for both beams |
| Deflection Control | Vertical deflection ≤ L/800 |
| Surface Treatment | Shot blasting, Sa2.5 standard |
| Welding Process | Automatic/semi-automatic (MIG) |
Product Advantages
-
High-strength steel structure with lightweight body and strong load-bearing capacity
-
Automated welding ensures consistent seams and high manufacturing accuracy
-
Shot blasting for corrosion resistance and extended service life
-
Double-flange wheels, buffers, and derailment protection ensure safe operation
-
Bolt connections enable easy installation and convenient maintenance
Applications
Ideal for light-duty environments such as equipment maintenance, workstation handling, assembly shops, warehouses, and logistics lines.
